Rode AI-1 USB Audio Interface

Rode

  • $179.00
    Unit price per
  • Save $20
Tax included.


RØDE’s AI-1 Audio Interface is packed with incredible technology to ensure recording on your computer is easy, versatile and sounds superb. The AI-1’s single input is a NeutrikTM Combo Jack, which takes both a 3-pole XLR (common to most microphones) and a quarter-inch jack common to most electric instruments like guitar, bass et al. Layering tracks is as easy as plug in, set level and go. Not only does the AI-1 deliver crystal clear audio to your computer software, but headphones have never sounded sweeter thanks to the discrete studio-quality headphone output and level control.
AI-1 Audio Interface Specifications


Computer Connectivity

USB


Form Factor

Desktop


Simultaneous I/O

1 x 2


Number of Preamps

1


Phantom Power

Yes


Bit Depth

24-bit


Sample Rates

44.1 kHz

48 kHz

88.2 kHz

96 kHz


Analog Inputs

1 x  Neutrik XLR-1/4” combo


Analog Outputs

2 x 1/4” (impedance balanced)

1 x 1/4” (headphones)


Direct Monitor

Yes


USB

1 x USB Type C


Bus Powered

Yes


OS Requirements

Mac OS 10.10 or later

Windows 7 or later


Power

USB bus-powered


Depth

100mm total (with knobs)

chassis: 88mm


Width

124mm


Height

38mm


Weight

1lb 3.7oz

560g



Input

XLR/MIC INPUT
Dynamic Range

104dBA


Equivalent Input Noise @ Maximum Gain (Source Impedance 150 ohms, 20Hz-20kHz, A-weighted)

–128dBA


Frequency Response (Measured after ADC)

20Hz – 20kHz better than ±1dB


Gain Range

0dB – >45dB


Gain Range

1.3k Ohms


INSTRUMENT INPUT
Dynamic Range

99dBA


Frequency Response (Measured after ADC)

20Hz – 20kHz better than ±1dB


Gain Range

0dB – >45dB


Input Impedance

900k Ohms



Output

MONITOR OUTPUTS
Maximum Output Level

-6dBu


Frequency Response

20Hz – 20kHz better than ±1dB


HEADPHONE
Max output power at 1% THD

32Ohms – >210mW

300Ohms – >390mW
